Answer : A

Nonstop bridging is a high availability capability focused on maintaining Layer 2 switching continuity during a Routing Engine switchover on platforms that support redundant control planes. The intent is to keep Layer 2 forwarding operational and minimize disruption to bridged traffic when the system transitions from a primary to a backup Routing Engine. Achieving this requires Graceful Routing Engine switchover, because GRES is the mechanism that enables a control plane switchover while keeping forwarding and interface state stable. With GRES in place, the forwarding plane can continue switching frames while the backup Routing Engine assumes control, reducing or eliminating traffic loss for Layer 2 domains.

Nonstop bridging is not the feature that preserves Layer 3 protocol sessions and routing information end-to-end. That function is associated with nonstop routing capabilities, which focus on maintaining routing protocol state across Routing Engine events. Therefore, stating that nonstop bridging preserves Layer 3 information and protocol sessions is incorrect. Likewise, nonstop active routing is not a requirement for nonstop bridging; it is a separate feature aimed at routing stability. The flow-control setting under gigether-options is unrelated to Routing Engine redundancy and does not determine whether nonstop bridging operates.

In data center access and aggregation environments where VLANs must remain stable for servers and appliances, nonstop bridging paired with GRES helps protect Layer 2 service continuity during control plane events.

Answer : B, C

A data center underlay IP fabric is a routed leaf-spine network designed to provide scalable Layer 3 connectivity between all fabric nodes. A key property of these fabrics is that there are multiple equal-cost paths between any two endpoints, typically across multiple spine devices. Equal-Cost Multi-Path load balancing is used to distribute traffic across those parallel paths. The routing table installs multiple next hops for the same destination prefix, and the forwarding plane selects an egress link per flow using a hash, which keeps packets in-order within a flow while using the fabric's aggregate bandwidth. This makes statement B correct.

Because the underlay is routed, loop avoidance is handled by the routing protocol and the fundamental properties of IP forwarding, not by spanning tree. Routing protocols compute a loop-free forwarding topology and use mechanisms like shortest-path calculation and next-hop selection so that even when multiple paths exist, traffic is forwarded along valid loop-free routes. This makes statement C correct. Statement D is incorrect because spanning tree is a Layer 2 loop prevention mechanism and is not required or desired in a routed underlay fabric. Statement A is also incorrect because traffic distribution depends on ECMP and forwarding behavior, not on all devices being the same hardware model. Mixed platforms can interoperate as long as the design accounts for capacity, features, and consistent routing behavior.

Answer : A, B

To advertise OSPF-learned routes to BGP neighbors on Junos, you must explicitly control route redistribution using policy. Junos does not automatically redistribute routes between routing protocols simply because both protocols are enabled. Instead, you create a routing policy that matches the routes you intend to export, in this case routes whose protocol origin is OSPF. The policy must accept those matched routes so they become eligible for advertisement.

After the policy is created, you must apply it as an export policy under the relevant BGP group or under the BGP protocol hierarchy, depending on your design. Export policy controls what your router sends to BGP peers. When the export policy accepts OSPF routes, Junos advertises those routes to the BGP neighbors in that group, subject to any additional BGP constraints such as next-hop handling, route families, and any peer-specific policy terms.

Creating a policy to match and accept BGP routes is not required for this goal because that would influence what routes are imported into your routing table from BGP, not what you export. Likewise, applying a policy as a BGP import policy affects received routes, not OSPF-to-BGP redistribution. In data center fabrics, this policy-driven approach prevents unintended route leakage and keeps redistribution tightly scoped to the prefixes that must be carried between domains.

Answer : C

Bidirectional Forwarding Detection is a lightweight, fast failure-detection mechanism used to quickly determine whether a forwarding path between two systems is operational. In Juniper data center networks, BFD is commonly paired with routing protocols such as BGP and OSPF to accelerate convergence. Instead of waiting for a routing protocol hold timer or dead interval to expire, BFD continuously exchanges small control packets between neighbors at a configured interval. If the local device stops receiving these control packets for a negotiated detection time, it declares the BFD session down.

This down event can then be used to immediately signal the routing protocol that the neighbor is no longer reachable, causing faster withdrawal of routes or faster reroute to alternate paths. This is critical in leaf-spine fabrics where rapid failover is expected to maintain application availability and to keep ECMP path sets current. BFD is designed to detect failures in the forwarding plane, including link failures, interface failures, or other failures that prevent packets from being successfully exchanged between the two endpoints. It is not intended to detect routing loops, and it does not specifically track route flaps as a function; flapping is a symptom that may occur when failures happen repeatedly.

Destination host unreachable messages are part of ICMP processing and are unrelated to BFD's purpose. In short, BFD's value is fast, protocol-independent failure detection for forwarding adjacency health.

Answer : D

An IP fabric underlay is the routed foundation of a modern leaf-spine data center. Its purpose is to provide scalable, deterministic Layer 3 reachability between all fabric nodes, typically using point-to-point routed links between leaves and spines. In this design, EBGP is commonly used as an underlay routing protocol because it scales well, supports clear policy boundaries, and enables fast convergence and operational simplicity. Each leaf forms EBGP sessions to each spine, advertising loopback addresses and link subnets so that overlay endpoints and control plane services can reach one another reliably.

RSTP is a Layer 2 spanning tree mechanism and is not the standard protocol for a routed underlay. EVPN is an overlay control plane used to distribute tenant reachability and multihoming information; it is not the underlay routing protocol itself. VXLAN is a data plane encapsulation used by the overlay to transport Layer 2 segments across a Layer 3 fabric; it also is not the underlay routing protocol.

In Juniper data center architectures, the underlay is intentionally kept simple and purely routed, while overlays such as EVPN VXLAN deliver multi-tenant Layer 2 and Layer 3 services on top of that underlay. EBGP fits the underlay requirement among the provided options.
