On the network shown in the figure, HOST A and HOST B are required to communicate with each other across VLANs through one-armed routing. To satisfy this requirement, which of the
following commands needs to be performed on G0/0/1.1 of RTA?
Answer : C
Understanding the Network Diagram
Host A is in VLAN 10 with a gateway of 10.0.1.254.
Host B is in VLAN 20 with a gateway of 10.0.2.254.
The router (RTA) has two sub-interfaces:
G0/0/1.1 (10.0.1.254/24) for VLAN 10
G0/0/1.2 (10.0.2.254/24) for VLAN 20
The switch (SWA) is using VLAN trunking to forward packets to the router, requiring 802.1Q encapsulation.
One-Armed Routing (Router-on-a-Stick) is being used, meaning a single physical interface (G0/0/1) handles multiple VLANs using sub-interfaces.
Analyzing the Answer Choices
Option A (dot1q termination vid 20) Incorrect
This command would be configured on G0/0/1.2, not G0/0/1.1.
Option B (dot1q termination vid 30) Incorrect
VLAN 30 is not part of this topology.
Option C (dot1q termination vid 10) Correct
Since G0/0/1.1 corresponds to VLAN 10, the correct command is dot1q termination vid 10.
Option D (dot1q termination vid 1) Incorrect
VLAN 1 is usually the default VLAN, which is not relevant here.
Thus, the correct answer is C (dot1q termination vid 10).
An ACL rule is as follows. Which of the following IP addresses can be matched by the permit rule?
Rule: rule 5 permit ip source 10.0.2.0 0.0.254.255
Answer : D
The wildcard mask 0.0.254.255 means:
The first and third octets are checked exactly.
The second and fourth octets can vary.
This results in a match for IPs in the range 10.0.2.0 - 10.0.2.255.
Only option D (10.0.2.1) falls within this range.
Thus, the correct answer is D (10.0.2.1).
