Google Professional Cloud Network Engineer Exam Dumps

Your organization recently created a sandbox environment for a new cloud deployment. To have parity with the production environment, a pair of Compute Engine instances with multiple network interfaces (NICs) were deployed. These Compute Engine instances have a NIC in the Untrusted VPC (10.0.0.0/23) and a NIC in the Trusted VPC (10.128.0.0/9). A HA VPN tunnel has been established to the on-premises environment from the Untrusted VPC. Through this pair of VPN tunnels, the on-premises environment receives the route advertisements for the Untrusted and Trusted VPCs. In return, the on-premises environment advertises a number of CIDR ranges to the Untrusted VPC. However, when you tried to access one of the test services from the on-premises environment to the Trusted VPC, you received no response. You need to configure a highly available solution to enable the on-premises users to connect to the services in the Trusted VPC. What should you do?

AAdd both multi-NIC VMs to a new unmanaged instance group, named nva-uig.
Create an internal passthrough Network Load Balancer in the Untrusted VPC, named ilb-untrusted, with the nva-uig unmanaged instance group designated as the backend.
Create a custom static route in the Untrusted VPC for destination 10.123.0.0/9 and the next hop ilb-untrusted.
Create an internal passthrough Network Load Balancer in the Trusted VPC, named ilb-trusted, with the nva-uig unmanaged instance group designated as the backend.
Create a custom static route in the Trusted VPC for destination 0.0.0.0/0 and the next hop ilb-trusted.

BAdd both multi-NIC VMs to a new unmanaged instance group, named nva-uig.
Create an internal passthrough Network Load Balancer in the Untrusted VPC, named ilb-untrusted, with the nva-uig unmanaged instance group designated as the backend.
Create a custom static route in the Untrusted VPC for destination 10.128.0.0/9 and the next hop ilb-untrusted.
Create an internal passthrough Network Load Balancer in the Trusted VPC, named ilb-trusted, with the nva-uig unmanaged instance group designated as the backend.
Create a custom static route in the Trusted VPC for destination 10.0.0.0/23 and the next hop ilb-trusted.

CAdd both multi-NIC VMs to a new unmanaged instance group, named nva-uigO.
Create an internal passthrough Network Load Balancer in the Untrusted VPC, named ilb-untrusted, with the nva-uigO as backend.
Create a custom static route in the Untrusted VPC for destination 10.128.0.0/9 and the next hop ilb-untrusted.
Add both multi-NIC VMs to a new unmanaged instance group, named nva-uigl.
Create an internal passthrough Network Load Balancer in the Trusted VPC, named ilb-trusted, with the nva-uigl as backend.
Create a custom static route in the Trusted VPC for destination 0.0.0.0/0 and the next hop ilb-trusted.

DAdd both multi-NIC VMs to a new unmanaged instance group, named nva-uig.
Create two custom static routes in the Untrusted VPC for destination 10.128.0.0/9 and set each of the VMs' NIC as the next hop.
Create two custom static routes in the Trusted VPC for destination 10.0.0.0/23 and set each of the VMs' NIC as the next hop.

Question 2

Your company's current network architecture has two VPCs that are connected by a dual-NIC instance that acts as a bump-in-the-wire firewall between the two VPCs. Flows between pairs of subnets across the two VPCs are working correctly. Suddenly, you receive an alert that none of the flows between the two VPCs are working anymore. You need to troubleshoot the problem. What should you do? (Choose 2 answers)

AVerify that the dual-NIC instance has not been added to a backend service.

BVerify that a public IP address has not been assigned to any network interface of the dual-NIC instance.

CUse Cloud Logging to verify that there were no modifications to the VPC firewall rules or policies that were applied to the two network interfaces of the dual-NIC instance.

DVerify that a VPC Service Controls perimeter has not been enabled for the project that contains the two VPCs and the dual-NIC instance.

EVerify that the dual-NIC instance has the --can-ip-forward attribute enabled.

Question 3

You are configuring the firewall endpoints as part of the Cloud Next Generation Firewall (Cloud NGFW) intrusion prevention service in Google Cloud. You have configured a threat prevention security profile, and you now need to create an endpoint for traffic inspection. What should you do?

ACreate a Private Service Connect endpoint within the zone, associate the endpoint to the VPC network, and use a firewall policy rule to apply the L7 inspection.

BCreate a firewall endpoint within the region, associate the endpoint to the VPC network, and use a firewall policy rule to apply the L7 inspection.

CCreate a firewall endpoint within the zone, associate the endpoint to the VPC network, and use a firewall policy rule to apply the L7 inspection.

DAttach the profile to the VPC network, create a firewall endpoint within the zone, and use a firewall policy rule to apply the L7 inspection.

Question 4

You configured a single IPSec Cloud VPN tunnel for your organization to a third-party customer. You confirmed that the VPN tunnel is established; however, the BGP session status states that BGP is not configured. The customer has provided you with their BGP settings:

Local BGP address: 169.254.11.1/30

Local ASN: 64515

Peer BGP address: 169.254.11.2

Peer ASN: 64517

Base MED: 1000

MD5 Authentication: Disabled

You need to configure the local BGP session for this tunnel based on the settings provided by the customer. You already associated the Cloud Router with the Cloud VPN Tunnel. What settings should you use for the BGP session?

APeer ASN: 64517
Advertised Route Priority (MED): 100
Local BGP IP: 169.254.11.2
Peer BGP IP: 169.254.11.1
MD5 Authentication: Disabled

BPeer ASN: 64515
Advertised Route Priority (MED): 100
Local BGP IP: 169.254.11.2
Peer BGP IP: 169.254.11.1
MD5 Authentication: Disabled

CPeer ASN: 64515
Advertised Route Priority (MED): 1000
Local BGP IP: 169.254.11.2
Peer BGP IP: 169.254.11.1
MD5 Authentication: Enabled

DPeer ASN: 64515
Advertised Route Priority (MED): 100
Local BGP IP: 169.254.11.1
Peer BGP IP: 169.254.11.2
MD5 Authentication: Disabled

Question 5

There are two established Partner Interconnect connections between your on-premises network and Google Cloud. The VPC that hosts the Partner Interconnect connections is named "vpc-a" and contains three VPC subnets across three regions, Compute Engine instances, and a GKE cluster. Your on-premises users would like to resolve records hosted in a Cloud DNS private zone following Google-recommended practices. You need to implement a solution that allows your on-premises users to resolve records that are hosted in Google Cloud. What should you do?

AAssociate the private zone to 'vpc-a.' Create an outbound forwarding policy and associate the policy to 'vpc-a.' Configure the on-premises DNS servers to forward queries for the private zone to the entry point addresses created when the policy was attached to 'vpc-a.'

BConfigure a DNS proxy service inside one of the GKE clusters. Expose the DNS proxy service in GKE as an internal load balancer. Configure the on-premises DNS servers to forward queries for the private zone to the IP address of the internal load balancer.

CUse custom route advertisements to announce 169.254.169.254 via BGP to the on-premises environment. Configure the on-premises DNS servers to forward DNS requests to 169.254.169.254.

DAssociate the private zone to 'vpc-a.' Create an inbound forwarding policy and associate the policy to 'vpc-a.' Configure the on-premises DNS servers to forward queries for the private zone to the entry point addresses created when the policy was attached to 'vpc-a.'
